Description
1. Engine: Cummins QSB6.7 electronic control diesel engine imported from the United States, with strong power, suitable for all-weather operation; Complies with National III emissions and smoke levels meet the latest national emission regulations;
2. Transmission: Heli self-made hydraulic reversing transmission+340 high-performance torque converter, manual and automatic intelligent shifting technology, smooth and impact free shifting, more convenient intelligent shifting, more efficient power matching, safe and reliable, and low noise
3. Drive axle:
CPCD120/135-CU1-09/06 III G models are equipped with a caliper disc brake drive axle,
CPCD120/135-CU3-09/06 III G models are equipped with wet brake drive axles,
Both of these bridges are dedicated drive axles for heavy-duty forklifts, equipped with a primary spiral main reduction device and a planetary drive wheel side reduction device, specifically designed for special working conditions of forklifts. The axle housing has high strength and load-bearing capacity;
4. Braking system:
The CPCD120/135-CU1-09/06 IIIG model adopts a pneumatic hydraulic braking system, which uses pneumatic top oil boosting technology to provide sufficient braking torque with very small control force. The caliper brake is stable, cost-effective, and applicable
The CPCD120/135-CU3-09/06 IIIG model adopts a wet braking system, which has stable working performance and is not affected by external humidity and dust. It is maintenance free, greatly reducing maintenance costs. The friction plates are immersed in oil for cooling, which can significantly reduce work efficiency
Meet the needs of ship cabins, smelting factories, as well as long-term, high-intensity, short distance, and frequent braking situations and operations, with a wider range of applications.
5. Air intake system: Select imported brand air filters to improve filtration accuracy, enhance power system efficiency and service life;
6. Hydraulic system: Adopting a top mounted hydraulic return oil main filter, with high filtration accuracy, the filter has no casing, low cost, and more convenient maintenance;
7. Lifting system: using comprehensive channel steel, the overall strength of the gantry is increased by 25% and 58%, the force on the rollers is reduced, the wear of the channel steel is reduced, the fatigue resistance is improved, and the service life is increased;
8. Driver's cab: Adopting the newly developed 360 ° driver's cab by Heli, it achieves a 360 ° panoramic view while meeting the strength of the skeleton; The entire vehicle is equipped with imported gray woven fabric materials for the Grammer fully suspended seats, which are comfortable to ride on. The control panel and seats
The base, radio, and radio are equipped with input ports and support for SD card external playback, providing drivers with a comprehensive and comfortable experience.
